Steel Mating Plates for INTERNATIONAL Gearbox
High-carbon Steel reaction plates for INTERNATIONAL (IH) transmission rebuilds. Precision ground. Replaces OEM 149585, 3041836R91.
Description
Package Information
Inquiry
Transmission Steel Plates
High-quality Steel Reaction Plates to pair with our friction discs. Manufactured with precise flatness to prevent drag in INTERNATIONAL machinery.
Model Specifications:
| OEM Part No. | Material | Teeth | Dimensions (mm) |
|---|---|---|---|
| 149585 | Steel | OT60 | 154.2 x 113.8 x 1.8 |
| 709527C1 | Steel | OL6 | 198.2 x 133.4 x 2.3 |
| 709808C91 | Steel | OL8 | 329.0 x 240.0 x 2.4 |
| 894083H1 | PSTD SI | IT32 | 146 x 78.6 x 2.0 |
| 922541C1 | CD PA | IT32 | 167.6 x 78.7 x 1.8 |
| 1202654H1 | SI | OT35 | 177.5 x 109 x 2.0 |
| 1202681H1 | SI | OT27 | 137.4 x 90.9 x 2.0 |
| 1222489C1 | Steel | OL8 | 437.0 x 343.0 x 2.4 |
| 1260006H1 | Steel | OL8 | 247.0 x 173.0 x 2.4 |
| 1260007H1 | Steel | OL8 | 247.0 x 173.0 x 2.4 |
| 1342285C1 | SI | IT19 | 203.2 x 57.2 x 4.7 |
| 3041836R91 | STCD SI | IT59 | 276.2 x 184 x 4.8 |
| 501314382 | PA | IT48 | 232.7 x 142 x 4 |
Get the full catalog? Email Us
