10300200 High-Performance Wet Friction Plate for Commercial Vehicle Transmissions – OEM Quality, ECE R90 Certified
The 10300200 friction plate delivers superior performance for commercial vehicle automatic transmissions (AMT/AT). Engineered with advanced wet paper-based composite, it ensures smooth shifting, 3x longer service life than sintered metal alternatives, and compliance with global environmental standards (copper-free ≤0.5%). Precisely matched to ZF, Eaton, and Allison transmissions, it’s ideal for fleet operators seeking cost-effective OEM replacements without compromising durability or efficiency.
Description
Package Information
Inquiry
| Attribute | Specification |
| Part Number | 10300200 |
| Application | Heavy-Duty AMT/AT Systems (Class 6-8 Trucks, Buses) |
| Material | Wet Paper-Based Composite |
| Friction Coeff. | μ=0.36±0.03 (SAE J661) |
| Temp. Range | 280°C Continuous / 350°C Peak |
| Compatibility | ZF TraXon, Eaton Endurant, Allison 3000 |
| Weight | 0.95 kg |
| Int. Diameter | 224 mm |
| Out. Diameter | 325 mm |
| Thickness | 4.5 mm |
| No. of Teeth | 54 |
